ข้อมูลจำเพาะทางเทคนิค Lutronic 1220 08 T20CW100 0,5m
Lutronic 1220 08 T20CW100 0,5m
- Product Type
- Industrial Circular Connector
- Number of Contacts
- 8
- Mount Type
- Panel
- Connector Size
- M12
- Current
- 2A
- Plug/Socket
- Socket
- Contact Gender
- Female
- IP Rating
- IP67
- Orientation
- Straight
- Series
- M12 1220
- Coding
- A Coded
- Voltage
- 30V
- Mating Type
- Threaded
- Minimum Operating Temperature
- -25°C
- Termination Type
- Wire
- Shell Size
- M12
- Housing Material
- Polyamide
- Maximum Operating Temperature
- 80°C
- Pole Format
- 8
- Standards/Approvals
- IEC 60664/DIN EN 60664/CTI UL Classification acc. to ANSI/UL 746A (for voltage Ratings and material group). Cable lists UL-style 1007, IEC DIN EN 60529 (for IP Rating)
- Contact Plating
- Gold Plated, Nickel
- Contact Material
- Copper Zinc Alloy
