ข้อมูลจำเพาะทางเทคนิค Lutronic 1230 12 T16CW 0,5m
Lutronic 1230 12 T16CW 0,5m
- Product Type
- Industrial Circular Connector
- Number of Contacts
- 12
- Mount Type
- Panel
- Current
- 1.5A
- Connector Size
- M12
- Plug/Socket
- Plug
- Contact Gender
- Male
- IP Rating
- IP67
- Orientation
- Straight
- Series
- M12 1230
- Coding
- L Coded
- Voltage
- 30V
- Minimum Operating Temperature
- -25°C
- Termination Type
- Wire
- Shell Size
- M12
- Mating Type
- Threaded
- Housing Material
- Copper Zinc Alloy, Nickel Plated, Polyamide
- Maximum Operating Temperature
- 80°C
- Pole Format
- 12
- Standards/Approvals
- IEC 60664/DIN EN 60664/CTI UL Classification acc. to ANSI/UL 746A, IEC DIN EN 60529 (for IP Rating)
- Contact Plating
- Gold Plated, Nickel
- Contact Material
- Copper Zinc Alloy
