ข้อมูลจำเพาะทางเทคนิค Lutronic 1245 04 T9CR
Lutronic 1245 04 T9CR
- Product Type
- Industrial Circular Connector
- Number of Contacts
- 4
- Current
- 4A
- Connector Size
- M12
- Plug/Socket
- Socket
- Contact Gender
- Female
- IP Rating
- IP67
- Series
- M12 1245
- Orientation
- Angled
- Voltage
- 150V
- Coding
- A Coded
- Termination Type
- Screw Clamp
- Shell Size
- M12
- Minimum Operating Temperature
- -25°C
- Maximum Operating Temperature
- 90°C
- Housing Material
- Nickel Plated, Fluoroelastomer, Copper Zinc Alloy, Polybutylene Terephthalate
- Pole Format
- 4
- Standards/Approvals
- IEC 60664/DIN EN 60664/CTI UL Classification acc. to ANSI/UL 746A, IEC DIN EN 60529 (for IP Rating)
- Contact Plating
- Gold Plated, Nickel
- Contact Material
- Copper Zinc Alloy
