Lutronic 1255 04 T9CR Industrial Circular Connector, 4 Contacts, M12 Connector, Plug, Male, IP67, M12 1255 Series

ข้อมูลจำเพาะทางเทคนิค Lutronic 1255 04 T9CR

Lutronic 1255 04 T9CR

Number of Contacts

4

Product Type

Industrial Circular Connector

Connector Size

M12

Current

4A

Plug/Socket

Plug

Contact Gender

Male

IP Rating

IP67

Orientation

Angled

Series

M12 1255

Coding

A Coded

Voltage

150V

Termination Type

Screw Clamp

Minimum Operating Temperature

-25°C

Shell Size

M12

Maximum Operating Temperature

90°C

Housing Material

Polybutylene Terephthalate, Nickel Plated, Fluoroelastomer, Copper Zinc Alloy

Pole Format

4

Standards/Approvals

IEC 60664/DIN EN 60664/CTI UL Classification acc. to ANSI/UL 746A, IEC DIN EN 60529 (for IP Rating)

Contact Plating

Gold Plated, Nickel

Contact Material

Copper Zinc Alloy
