ข้อมูลจำเพาะทางเทคนิค Lutronic 1255 05 T9CR
Lutronic 1255 05 T9CR
- Product Type
- Industrial Circular Connector
- Number of Contacts
- 5
- Current
- 4A
- Connector Size
- M12
- Plug/Socket
- Plug
- Contact Gender
- Male
- IP Rating
- IP67
- Series
- M12 1255
- Orientation
- Angled
- Coding
- A Coded
- Voltage
- 36V
- Termination Type
- Screw Clamp
- Minimum Operating Temperature
- -25°C
- Shell Size
- M12
- Housing Material
- Fluoroelastomer, Copper Zinc Alloy, Polybutylene Terephthalate, Nickel Plated
- Maximum Operating Temperature
- 90°C
- Standards/Approvals
- IEC 60664/DIN EN 60664/CTI UL Classification acc. to ANSI/UL 746A, IEC DIN EN 60529 (for IP Rating)
- Pole Format
- 5
- Contact Plating
- Gold Plated, Nickel
- Contact Material
- Copper Zinc Alloy
