ข้อมูลจำเพาะทางเทคนิค Lutronic 7830 04 T13CW 0,5m
Lutronic 7830 04 T13CW 0,5m
- Number of Contacts
- 4
- Product Type
- Industrial Circular Connector
- Mount Type
- Panel
- Current
- 12A
- Connector Size
- 7/8 in
- Plug/Socket
- Plug
- Contact Gender
- Male
- IP Rating
- IP67
- Series
- 7830
- Orientation
- Straight
- Coding
- A Coded
- Voltage
- 250V
- Termination Type
- Wire
- Mating Type
- Threaded
- Minimum Operating Temperature
- -25°C
- Maximum Operating Temperature
- 80°C
- Housing Material
- Copper, Nickel Plated, Thermoplastic Polyurethane, Zinc
- Standards/Approvals
- IEC 60664/DIN EN 60664/CTI UL Classification acc. to ANSI/UL 746A, IEC DIN EN 60529 (for IP Rating)
- Pole Format
- 4
- Contact Plating
- Gold Plated, Nickel
- Contact Material
- Copper Zinc Alloy
