ข้อมูลจำเพาะทางเทคนิค MEAN WELL N7809-2CW
MEAN WELL N7809-2CW
- Product Type
- DC/DC Converter
- Output Voltage 1
- 9V dc
- Maximum Input Voltage
- 24V dc
- Minimum Input Voltage
- 24V dc
- Mount Type
- Through Hole
- MTBF
- 1600kH
- Ripple and Noise
- 100mV Pk-Pk
- Output Current 1
- 2A
- Maximum Output Power
- 30W
- Length
- 11.5mm
- Depth
- 17.5mm
- Weight
- 5.5g
- Standards/Approvals
- EN61000-4-4, EN61000-4-6, EN61000-4-3, EAC TP TC 020 2011N A, EN61000-4-2, EN61000-4-5, BS EN EN55032
- Width
- 9mm
- Series
- N7809
- Maximum Operating Temperature
- 85°C
- Efficiency
- 0.96
- Minimum Operating Temperature
- -40°C
