ข้อมูลจำเพาะทางเทคนิค MEAN WELL RSDW60F-03
MEAN WELL RSDW60F-03
- Output Voltage 1
- 3, 3.6V dc
- Product Type
- DC/DC Converter
- Maximum Input Voltage
- 36V dc
- Minimum Input Voltage
- 9V
- Output Current 1
- 12A
- Mount Type
- Through Hole
- MTBF
- 205kH
- Isolation Voltage
- 500V
- Maximum Output Power
- 60W
- Package Type
- Metal case
- Series
- RSDW
- Standards/Approvals
- EN50155 / IEC60571 / EN61373 / EN50121-3-2 / EAC TP TC 020/2011
- Depth
- 10.5mm
- Weight
- 37.6g
- Length
- 50.8mm
- Width
- 25.4mm
- Minimum Operating Temperature
- -40°C
- Efficiency
- 0.89
- Maximum Operating Temperature
- 85°C
