ข้อมูลจำเพาะทางเทคนิค Phoenix Contact 1701061
Phoenix Contact 1701061
- Product Type
- PCB Terminal Block
- Number of Contacts
- 9
- Pitch
- 2.5mm
- Current
- 4A
- Number of Rows
- 1
- Mount Type
- Push-in
- Housing Material
- Polyamide
- Connector Gender
- Female
- Termination Type
- Socket
- Colour
- Black
- Voltage
- 160V
- Depth
- 11.75mm
- Series
- FK-MC
- Width
- 23.1mm
- Standards/Approvals
- IEC 60999-1:1999-11, EN 60695-2-13, IEC 60512-1-1:2002-02, IEC 60512-13-5:2006-02, UL 94, EN 60695-2-12, UL Recognised Approval ID: E60425-20230810, JEDEC JESD 201, IEC 60664-1:2007-04, IEC 60068-2-82, IEC 60112, IEC 60512-1-2:2002-02, VDE approval ID: 40057836, cULus Recognised Approval ID: E60425-20230810, IEC 60068-2-70:1995-12, EN ISO 22479:2022-06, EN 60695-10-2, IEC 60512-13-2:2006-02
- Length
- 19.05mm
