Phoenix Contact 1754827 FKCN 2 Series PCB Connector, 5-Contact, 5.08 mm Pitch, Screw, 1 Row Push-in Spring

ข้อมูลจำเพาะทางเทคนิค Phoenix Contact 1754827

Phoenix Contact 1754827

Product Type

PCB Connector

Number of Contacts

5

Pitch

5.08mm

Number of Rows

1

Current

12A

Housing Material

Polyamide

Mount Type

Screw

Connector Gender

Female

Termination Type

Push-in Spring

Colour

Green

Contact Gender

Female

Voltage

320V

Series

FKCN 2

Length

27.1mm

Depth

10.9mm

Standards/Approvals

IEC 60999-1, IEC 60512-13-2, IEC 60512-13-5, IEC 60512-1-1, IEC 60512-1-2, IEC 60068-2-70, IEC 60068-2-6, IEC 60512-9-1, EN ISO 22479, IEC 60068-2-27, IEC 60512-5-1, IEC 60512-3-1, IEC 60664-1, UL 94, EN 60695-2-12, EN 60695-2-13, EN 60695-10-2, DIN 46228โ€1, DIN 46228โ€4, cULus Recognised, VDE approval

Width

35.4mm
