ข้อมูลจำเพาะทางเทคนิค Phoenix Contact 1768004
Phoenix Contact 1768004
- Product Type
- PCB Terminal Block
- Number of Contacts
- 4
- Pitch
- 2.5mm
- Number of Rows
- 1
- Current
- 4A
- Housing Material
- Polyamide
- Mount Type
- Push-in
- Colour
- Black
- Termination Type
- Screw
- Contact Gender
- Female
- Voltage
- 160V
- Series
- FK-MC
- Width
- 10.6mm
- Standards/Approvals
- cULus Recognised Approval ID: E60425-19990913, VDE report with production monitoring Approval ID: 40013394, IEC 61984, IEC 60999-1:1999-11, IEC 60512-13-2:2006-02, IEC 60512-13-5:2006-02, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60068-2-6:2007-12, IEC 60512-9-1:2010-03, ISO 6988:1985-02, IEC 60512-5-1:2002-02, IEC 60512-3-1:2002-02, IEC 60664-1:1992-10 + A1:2000-02 + A2:2002-05, DIN 46228โ€1, JEDEC JESD 201, IEC 60068-2-82, IEC 60112, UL 94 V0, EN 60695-2-12, EN 60695-2-13, EN 60695-10-2
- Depth
- 11.75mm
- Length
- 19.05mm
