ข้อมูลจำเพาะทางเทคนิค Phoenix Contact 1769171
Phoenix Contact 1769171
- Product Type
- PCB Connector
- Number of Contacts
- 6
- Pitch
- 5.08mm
- Number of Rows
- 1
- Current
- 8A
- Housing Material
- Polyamide
- Mount Type
- Screw
- Connector Gender
- Female
- Termination Type
- Screw
- Colour
- Green
- Voltage
- 320V
- Contact Gender
- Female
- Length
- 18.9mm
- Series
- FRONT-MSTB 2
- Width
- 40.28mm
- Standards/Approvals
- cULus Recognised, VDE approval of drawings, IEC 60999-1:1999-11, IEC 60512-13-2:2006-02, IEC 60512-13-5:2006-02, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60068-2-70:1995-12, IEC 60068-2-6:2007-12, IEC 60512-9-1:2010-03, ISO 6988:1985-02, IEC 60512-5-1:2002-02, IEC 60512-3-1:2002-02, IEC 60664-1:2007-04, IEC 60112, UL 94, EN 60695-2-12, EN 60695-2-13, EN 60695-10-2
- Depth
- 15mm
