ข้อมูลจำเพาะทางเทคนิค Phoenix Contact 1806041
Phoenix Contact 1806041
- Number of Contacts
- 6
- Product Type
- PCB Connector
- Pitch
- 7.62mm
- Current
- 12A
- Number of Rows
- 1
- Housing Material
- Polyamide
- Mount Type
- Screw
- Connector Gender
- Female
- Colour
- Green
- Termination Type
- Screw
- Voltage
- 630V
- Depth
- 15mm
- Series
- FRONT-GMSTB 2
- Width
- 56.34mm
- Standards/Approvals
- IEC 61984, IEC 60999-1:1999-11, IEC 60512-13-2:2006-02, IEC 60068-2-70:1995-12, IEC 60512-13-5:2006-02, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60068-2-6:2007-12, IEC 60512-9-1:2010-03, EN ISO 22479:2022-06, EN 60695-2-12, EN 60695-2-13, EN 60695-10-2, UL 94 V0, CSA Approval ID: 13631-2585951, cULus Recognised Approval ID: E60425-19931011, VDE approval of drawings Approval ID: 40050694, EU RoHS
- Length
- 27.3mm
