ข้อมูลจำเพาะทางเทคนิค Phoenix Contact 1905706
Phoenix Contact 1905706
- Product Type
- PCB Terminal Block
- Number of Contacts
- 5
- Pitch
- 5mm
- Current
- 24A
- Number of Rows
- 1
- Housing Material
- Polyamide
- Minimum Wire Size mm²
- 0.2mm²
- Maximum Wire Size mm²
- 2.5mm²
- Connector Gender
- Female
- Minimum Wire Size AWG
- 24AWG
- Maximum Wire Size AWG
- 14AWG
- Colour
- Green
- Wire Connection Method
- Screw Connection with Tension Sleeve
- Voltage
- 400V
- Standards/Approvals
- cULus Recognised, EAC, IECEE CB Scheme, SEV, VDE Gutachten mit Fertigungsuฬberwachung
- Depth
- 18.5mm
- Width
- 25mm
- Length
- 9.5mm
- Series
- MKDSN 2
