ข้อมูลจำเพาะทางเทคนิค TE Connectivity 606710/49-13-20-150-15/000
TE Connectivity 606710/49-13-20-150-15/000
- Contact Configuration
- DPDT
- Product Type
- Toggle Switch
- Switch Operation
- On-Off-On
- Switch Contact Current
- 20A
- Mount Type
- Panel
- Terminal Type
- Tab
- IP Rating
- IP67
- Minimum Operating Temperature
- -20°C
- Actuator Length
- 17.5mm
- Contact DC Voltage
- 30V dc
- Maximum Operating Temperature
- 70°C
- Actuator Material
- Brass
- Length
- 17.48mm
- Series
- AWT
- Standards/Approvals
- RoHS
- Mechanical Life
- 40000Cycles
