ข้อมูลจำเพาะทางเทคนิค TRACOPOWER TEL 10-4813WI
TRACOPOWER TEL 10-4813WI
- Product Type
- DC/DC Converter
- Output Voltage 1
- 15V dc
- Minimum Input Voltage
- 18V
- Maximum Input Voltage
- 75V dc
- Output Current 1
- 666mA
- Mount Type
- PCB
- Input Ratio
- 04:01:00.000
- Number of Outputs
- 1
- MTBF
- 2540000h
- Isolation Voltage
- 1kV dc
- Package Type
- DIP-16
- Maximum Output Power
- 10W
- Standards/Approvals
- No
- Depth
- 8mm
- Length
- 23.8mm
- Series
- TEL 10WI
- Width
- 13.7mm
- Minimum Operating Temperature
- -40°C
- Efficiency
- 0.88
- Maximum Operating Temperature
- 88°C
- 3D Model
- https://www.traceparts.com/els/rs-components/en/api/viewer/3d?SupplierID=RS_COMPONENTS&PartNumber=1764640&DisplayLogo=False
