ข้อมูลจำเพาะทางเทคนิค MEAN WELL XDR-75E-24
MEAN WELL XDR-75E-24
- Series
- XDR-75E
- Product Type
- DIN Rail Power Supply
- Sub Type
- DIN Rail
- Maximum Output Voltage
- 24V
- Electrical Phase
- 1
- Number of Outputs
- 1
- Input Voltage Type
- AC/DC
- Power
- 76.8W
- Output Current
- 3.2A
- Remote signal DC-OK
- Yes
- Minimum Operating Temperature
- -40°C
- Output Voltage Type
- DC
- Maximum Operating Temperature
- 70°C
- Width
- 30mm
- Standards/Approvals
- UL61010, TUV BS EN EN61010 IEC61010, RCM ASNZS 61558116, KC KC6681, IEC615581, EAC TPTC004, CCC GB494.1, CB IEC6681, BSMI CNS1 1, BS ENEN6681, BS ENEN61558116, BIS IS15 (Part 1):010, 5598 ASNZS 6681
- Hazardous Area Certification
- No
- Height
- 125.2mm
- Depth
- 116mm
- Maximum Input Voltage
- 264V ac
- Minimum Input Voltage
- 85V ac
- Efficiency
- 0.89
