ข้อมูลจำเพาะทางเทคนิค RS PRO DB3C-A1LC
RS PRO DB3C-A1LC
- Product Type
- Micro Switch
- Actuator Type
- Short Roller Lever
- Terminal Type
- Quick Connect
- Switch Contact Current
- 16A
- Housing Material
- Glass Filled Thermoplastic
- Contact Configuration
- SPDT
- IP Rating
- IP40
- Operating Force
- 240g
- Minimum Operating Temperature
- -55°C
- Maximum Operating Temperature
- 85°C
- Microswitch Type
- Miniature Microswitch
- Contact AC Voltage
- 250V ac
- Contact DC Voltage
- 220V dc
- Hazardous Area Certification
- No
- Mechanical Life
- 1000000Operations
- Depth
- 10.3mm
- Length
- 27.8mm
- Standards/Approvals
- CE, IEC 1508-1
- Width
- 15.9mm
- Series
- RS PRO
