ข้อมูลจำเพาะทางเทคนิค TE Connectivity 84-ASKS-C19-04A9
TE Connectivity 84-ASKS-C19-04A9
- Contact Configuration
- DPDT
- Product Type
- Toggle Switch
- Switch Operation
- On-Off-On
- Switch Contact Current
- 5A
- Mount Type
- Panel
- Terminal Type
- Solder
- Minimum Operating Temperature
- -30°C
- Contact AC Voltage
- 125V ac
- Contact DC Voltage
- 28V dc
- Actuator Length
- 12.32mm
- Maximum Operating Temperature
- 85°C
- Standards/Approvals
- RoHS
- Length
- 0.5in
- Width
- 0.45in
- Mechanical Life
- 6000Cycles
